How to build Op-Amp Booster Designs - PDF

October 4, 2010 - category: General electronics


Although modern integrated circuit operational amplifiers ease linear circuit design, IC processing limits amplifier output power. Many applications, however, require substantially greater output voltage swing or current (or both) than IC amplifiers can deliver. In these situations an output “booster,” or post amplifier, is required to achieve the needed voltage or current gain. Normally, this stage is placed within the feedback loop of the operational amplifier so that the low drift and stable gain characteristics of the amplifier are retained.

Op-Amp Booster Designs - PDF

Because the booster is a gain stage with its own inherent AC characteristics, the issues of phase shift, oscillation, and frequency response cannot be ignored if the booster and amplifier are to work well together. The design of booster stages which achieve power gain while maintaining good dynamic performance is a difficult challenge. The circuitry for boosters will change with the application’s requirements,which can be very diverse.

This application note explains the following designs with diagrams and definitions.

  1. 200 mA Current Booster
  2. Ultra High Speed Fed-Forward Current Booster
  3. Voltage-Current Booster
  4. ±120V Swing Booster
  5. High Current Booster
  6. Indestructible, Floating Output Booster
  7. 1000V-300 mA Booster
  8. 300V Output Booster

circuit from http://www.extremecircuits.net/2010/05/op-amp-booster-designs.html
